Monoblock selector 2 positions key - EMS

€6.78 Tax included

€5.60 tax excl.

Key-operated monoblock pushbutton, 2 maintained positions. Diameter of the fixing hole 20,2mm. Different models with open contact (1NO, 2NO) and closed contact (1NC, 2NC) or 1 open contact and 1 closed contact (1NO+1NC).

Product manufactured in Europe.

Part number: MKB06xA0






Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

Type of contact
  • 1 Open (1NO)

No queries yet, leave the first!


Key-operated monoblock pushbutton, 2 positions maintained. Diameter of the fixing hole 20,2mm. Different models with open contact (1NO, 2NO) and closed contact (1NC, 2NC) or 1 open contact and 1 closed contact (1NO+1NC).

Different models available:

  • 1 contact open (1NO)
  • 1 contact closed (NC)
  • 1 contact open and 1 contact closed (1NO+1NC)
  • 2 open contacts (2NO)
  • 2 contacts closed (2NC)



Characteristics:

  • Manufacturer: EMS
  • Part number: MKB06xA0
  • Maximum rated voltage: 230Vac
  • Thermal current: 10A
  • Maximum rated current at 24Vac: 1,5A
  • Maximum rated current at 120Vac: 6A
  • Maximum rated current at 120Vac: 6A
  • Frequency: 50-60Hz
  • Nominal voltage from isolation: 600Vac
  • Resistance of isolation at 500Vdc: 50Mohms
  • Contact resistance: 20Mohms
  • Contact electrical life: 500,000 cycles
  • Terminals: Suitable for flexible or solid conductors from 2x1mm2 to 2x2.5mm2
  • Contact material: AgNi
  • Cable connection type: Screw
  • Tightening torque: 0.8Nm
  • Degree of protection: IP65
  • Usage category: AC-15, DC-13
  • Standard: IEC-60947-5-1
  • Certifications: CE, ROHS, UL



Contact arrangement:




Dimensions and mounting:






Material for professional use, install in compliance with the regulations in force at the place of installation
