1-female 2- way shut-off valve with lever - Aignep
1-female 2- way shut-off valve with lever - Aignep

1-female 2- way shut-off valve with lever - Aignep

€16.07 Tax included

€13.28 tax excl.

Shut-off valve or G1 female ball valve (ISO 228 compliant), 2- way , lever operation. Made of chromed brass. Valve for pneumatic applications of compressed air, tools, automation, food and beverages, plumbing, vacuum and inert gases, thermo-hydraulic sector.


Series: GHILUX
Reference: 6067 1

aignep
mini-regulation
Representative image for illustrative purposes, the item supplied will correspond to the indicated specifications.

No queries yet, leave the first!


Two way G1 female ball valve (ISO 228 compliant) with lever operation. Body made of nickel-plated brass, plastic-coated steel maneuver cam and PTFE ball head gasket. These excellent performance valves ensure a reliable seal and secure connection between components. They are used to close the air passage in various pneumatic applications such as tools and compressed air, automation, thermo-hydraulic sector, food and beverages, life & science, plumbing, vacuum, inert gases, fluid interception, etc.

These on-off type valves have two possible positions, open or closed . In the ON position, the fluid from the circuit passes through the valve and when it is in the OFF position, it completely blocks the flow of fluid.


6067drawing1


Technical characteristics:

  • Manufacturer: Aignep
  • Reference: 6067 1
  • Thread: Female 1 (Gas cylindrical thread conforming to ISO 228)
  • Material: Chromed brass
  • Application fluids: Compressed air / Water
  • Pressure (up to DN 20): See values represented in the diagram
  • Pressure (DN25 - DN 50): Max. 18bar
  • Thread regulations:
    • Gas conforms to ISO 7.1, BS 21, DIN 2999
    • Cylindrical gas according to ISO 228 Class A
    • NPTF Metric conforms to ANSI B1.20.5


Pressure - temperature diagram:

6067diagrampretem

Dimensions:

6067drawing2
6067TD





For more information you can download the technical sheet by clicking on the "Attachments" tab
.

Material for professional use, install in compliance with the regulations in force at the installation site.
