Bearing 3205-2RS FAG 25x52x20.6 mm

€42.59 Tax included

€35.20 tax excl.

3205-2RS double row angular contact ball bearing,dimensions 25x52x20.6mm, sealed with two lip caps for closure (2RS) on both sides and polyamide cage.

Brand FAG.

Ref: 3205 B-2RSTVH

Logo-FAG

Representative image for illustrative purposes, the article supplied shall correspond to the specifications indicated.

No queries yet, leave the first!


Angular contact ball bearing, double row, 3205-2RS series according to DIN 628-3, two rows of balls, sealed with metal protective caps for closing both sides. are already supplied lubricated. Polyamide cage.

This series of bearings with 2RS suffix (2RSR) are protected from protective caps on both sides of the bearing, this type of contact seals are ideal for protection against dust, dirt and wet environments.

Double row angular contact ball bearings support high radial loads and axial forces in both directions, the contact angle of this series is 25o.

This type of bearings are suitable for operating temperatures from -30oC to +110oC.

Dimensions: .25x.52x20.6.

For other references or measures consult.

Dimensiones doble hilera contacto angular

characteristics:

  • Manufacturer FAG - INA.
  • Reference: 3205 B-2RSTVH
  • Material: Tempered steel.
  • Dimension d: 25mm.
  • Dimension D: 52mm.
  • Dimension B: 20.6mm.
  • Sealing: Elastic type 2RS (2RSR) (NBR) on both sides.
  • Dynamo load capacity Cr (N): 21200.
  • Static load capacity C₀r (N): 14600.
  • Contact Angle: ἀ-25o
  • Limit speed ng (min⁻1): 7500.
  • Weight: 0.182Kg.

Material for professional use, install in compliance with the regulations in force at the place of installation.
