Circuit breaker 1 pole 6A - Hyundai Electric

€5.90 Tax included

€4.88 tax excl.

MCB circuit breaker 1 pole 6A curve C, for protection against short circuits and overloads. With an breaking capacity of 6000A. Active protection with individual status indication.

Reference: HGD63-M1P006C

Esquema electrico magnetotermico 1 polos

No queries yet, leave the first!


MCB circuit breaker 1 pole 6A 6kA curved "C", for protection against short circuits and overloads in machinery. With an assigned cutting power of 6kA, active protection of the poles with status indication. Made of fireproof thermoplastic material. Manufactured according to reference regulations IEC/EN60898-1. High reliability and performances allowing a high number of duty cycles.

As main features of this product range we can review:

  • Compact design and structure.
  • 13 plates in the extinguishing chamber for effective arc cooling.
  • Free firing mechanism. The switch fires even if maintenance is forced in the on position (ON).
  • Visual status indication.
  • Supports mounting a large number of accessories.

Technical details:

  • Manufacturer/Supplier: Hyundai Electric.
  • Manufacturer's Reference: HGD63-M1P006C.
  • Nominal MCB circuit breaker intensity (In): 6A.
  • Number of poles: 1
  • Step: 1 module.
  • Cutting power (Icn): 6000A (6kA) (Ics-100% icn).
  • Maximum operating voltage (Eu): 240/415Vac, 50/60Hz.
  • Characteristic curve: C.
  • Assigned insulation voltage (Ui): 500Vac.
  • Rated pulse resistance voltage (Uimp): 4 KV.
  • Dielectric resistance: 2.5kV.
  • Protection: IP20.
  • Enduring: ≥10000/20000.
  • Operating temperature: -5oC... +55oC.
  • Humidity: 95% RH.
  • Energy limitation class: Class 3.
  • Terminal type: Screw tightening jaw.
  • Maximum terminal capacity: 25mm2.
  • Maximum tightening torque: 2 Nm.
  • Weight: 0.100 Kg.
  • Dimensions (mm): 80.5x71x17.7 mm
  • Mounting position: Vertical/Horizontal.
  • Housing and cover material: Ignifugo molded thermoplastic.
  • Supports mounting of auxiliary elements: SI.
  • Regulations: EC; IEC/EN 60898-1.

Dimensiones magnetotermicos HCG63N
