Switch disconnector with rotary handle 3 poles 40A
Switch disconnector with rotary handle 3 poles 40A

Switch disconnector with rotary handle 3 poles 40A

€15.32 Tax included

€12.66 tax excl.

40A 3-pole rotary load-cutting Switch disconnector . Its compact design with rotating handle allows easy and comfortable handling when using it for power interruption. DIN rail mounting.

This device ensures load maneuvering and safety sectioning of the entire installation.


Reference: EVOMS40/3


Representative image for illustrative purposes, the item supplied will correspond to the indicated specifications.

No queries yet, leave the first!


Load cut-off disconnector switch with 3- pole 40A Switch disconnector knob . Intended for a wide variety of applications such as a main switch, maintenance or repair switch, on/off switch, safety switch, etc. DIN rail mounting or fixing with screws.

This type of switch ensures load maneuvering and safety sectioning of the entire electrical circuit. They can be mounted in standard distribution cabinets or boxes along with other electrical switchgear elements such as circuit breakers and differentials. Allows locking with a padlock.




Characteristics:

  • Manufacturer/Supplier: Tracon
  • Reference: EVOMS40/3
  • Number of poles: 3
  • Rated voltage: 400Vac 50Hz
  • Rated current: 40A
  • Rated operating power in AC3 at 400V: 40kW
  • Rated insulation voltage (Ui): 800Vac
  • Operating temperature: -25ºC...+55ºC
  • Protection grade: IP20
  • Conductor section: 1.5 - 16mm²
  • Padlockable
  • Regulations: EN 60947-3


Dimensions:

A: 73.3mm; B: 81mm; C: 65.5mm; D: 75.5mm; E: 36.5mm





Material for professional use, install in compliance with the regulations in force at the installation site.
