4 Pole Disconnector 40A - Tracon

Name: 4 Pole Disconnector 40A - Tracon
Brand: TRACON
SKU: TIK4-40
Price: 18.4646 EUR
Availability: PreOrder

€18.46 Tax included

€15.26 tax excl.

4-pole 40A load cut-off Switch disconnector . Din rail mounting, 4 modules wide. With firing indicator.

Reference: TIK4-40

Representative image for illustrative purposes, the item supplied will correspond to the indicated specifications.

No queries yet, leave the first!

Privacy

Shipments

Returns

4-pole, 40A load cut-off disconnector for disconnecting voltage in an electrical installation or machine. Modular design, 4 modules wide for DIN rail mounting. It has a firing indicator.

Characteristics:

Manufacturer/Supplier: Tracon
Reference: TIK4-40
Number of poles: 4
Rated voltage: 230Vac 50/60Hz
Rated current: 40A
Rated insulation voltage (Ui): 690Vac
Rated impulse withstand voltage (Uimp): 6kV
Electrical life: > 10000 cycles
Mechanical life: > 20000 cycles
Operating temperature: -25ºC...+55ºC
Protection grade: IP20
Conductor section: 1.5 - 50mm²
Allows the use of pin-type connection combs
Sealable in OFF position
Regulations: EN 60947-3

Attention: This component should not be confused with a circuit breaker, they are two different elements.

Dimensions:

Material for professional use, it must be installed by qualified personnel, respecting the regulations in force at the installation site.

Annex instructions for use elec.

Document attached to the instructions for use of electrical equipment

Download (402.62KB)

Anexo instruções utilização elec

Download (414.22KB)

Annexe mode d'emploi elec.

Download (410.39KB)

Annex instructions for use elec.

Download (410.3KB)

Allegato istruzioni l'uso elec

Download (406.25KB)

Anhang Gebrauchsanweisung elec

Download (412.12KB)
