Tensioner bracket with bearing 35mm shaft INOX UCT207 - ISB

€117.90 Tax included

€97.44 tax excl.

Tensioning support with bearing inserted UCT207, both elements in stainless steel, for shaft diameter 35mm. Self-aligning support bracket with bearing ball bearing inserted with studs in the inner ring, sheet metal seal with nitrile rubber lip. Bearing with spherical outer rings for self-alignment and to compensate for misalignment.


Part number: SSUCT207

Logo-ISB


Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!


Tensioning support bracket with insert already mounted, both elements in stainless steel type UCT207, for Ø35mm shaft.


The body of the support bracket of bearing in AISI 304 stainless steel protected against corrosion. High load capacity.

The bearing ball insert in AISI 440 C stainless steel. These bearings are grooved. Their outer rings have a spherical surface that is free to oscillate in the housing raceway, this oscillation allows self-alignment in the housing housing housing and compensates for any misalignment and eliminates, as far as possible, unwanted stresses between the shaft and the housing. The bearing is fixed to the shaft by means of two screws allen hexagonal offset 120º. Easy assembly and disassembly.


The field of application of these housings with stainless steel bearings are industries, food, petrochemical, chemical, humid or saline environments, in cleaning and pressure washing equipment... with normal loads, low to medium rotation speeds.

The tightness of the bearing is guaranteed by means of a gasket composed of a stainless steel protection plate plus rubber sealing, the bearing has a gasket on each side. This protection system avoids grease leakage and any possible infiltration of contaminating agents, which is particularly indicated when there are very aggressive external agents, dust, liquids or when the machine is working outdoors.

The bearings are suitable for all applications in a temperature range from -15°C to +100°C.

Delivery includes (already mounted):

  • Housing: UCT207 in INOX
  • Insert (bearing): UC207 in INOX

Main dimensions:

SSUCTDIMENSIONES

  • d: 35mm
  • o: 16mm
  • g: 13mm
  • p: 64mm
  • q: 37mm
  • s: 22mm
  • b: 64mm
  • k: 12mm
  • e: 89mm
  • a: 102mm
  • w: 129mm
  • j: 37mm
  • l: 30mm
  • h: 78mm
  • t: 59,5mm
  • B: 42,9mm
  • N: 17,5mm
  • Weight: 1,92Kg

For other references or models please consult.


Material for professional use, install in compliance with current regulations at the place of installation .
