Socket for intermediate connection diameter 63mm female downpipe 1 - Sicomat
Socket for intermediate connection diameter 63mm female downpipe 1 - Sicomat

Socket for intermediate connection diameter 63mm female downpipe 1 - Sicomat

€49.11 Tax included

€40.59 tax excl.

Air intake for branches and intermediate connections, for 63mm outer diameter tube and for downpipe with 1 cylindrical female thread. Branch with anti-condensation system for creating downpipes in compressed air, vacuum and inert gas networks and installations.

Its internal design allows the use of air without any type of condensate, which remains in the main line. Its manufacturing geometry prevents condensed water from accessing the downspout, improving air quality at the work intake. Element that is easy and quick to assemble in already finished installations without having to dismantle them.


Reference: R208.063.063




Representative image for illustrative purposes, the item supplied will correspond to the indicated specifications.

No queries yet, leave the first!


Air intake for creating downpipes or branches of the main pipe network in already finished installations, for main pipe with an external diameter of 63mm and for downspouts with 1 cylindrical female thread. This element has an anti-condensation design for creating downpipes. in networks of compressed air, vacuum and inert gases such as nitrogen and argon. Designed with a quick coupling system that guarantees easy assembly in already finished installations without having to dismantle them. Maximum working pressure 12.5 bar .






Characteristics:

  • Manufacturer/Supplier: Sicomat/Metalwork
  • Reference: R208.063.063
  • Pipe diameter: 63mm
  • Downpipe thread: Female 1 (Gas cylindrical conforming to ISO 228)
  • Application: Compressed air / Vacuum / Nitrogen
  • Maximum pressure conditions: -0.8 to 12.5bar
  • Temperature conditions: -20ºC to +70ºC
  • Dimensions: Ø = 63mm; A = 134mm; B = 146.5mm; C= 80mm; D = 1"
  • Weight: 974g
  • All products in the SicoAir Line range meet the requirements of 2014/68/EU (Pressure Equipment Directive), ASME B31.1 requirements, are non-flammable and limit the spread of flame.










Material for professional use, install in compliance with the regulations in force at the installation site.
