Tetrapolar load cutting disconnector switch 4x400A - Hyundai Electric

€404.64 Tax included

€334.41 tax excl.

Load cut disconnector switch in molded box format 4 poles of 400A of nominal intensity. Switch for disconnection without protection function with high operating capacity under load and with a high level of insulation in sectioning, high reliability and safety in anomalous situations. High electrical and mechanical life.

Reference: HGM400-NA4PDS400




Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!


Switch-disconnecter of cut in load in molded box format 4 poles of 400A of nominal intensity. It is a switch for disconnection under load without protection function, with high operating capacity under load and with a high level of insulation in sectioning, high reliability and safety in anomalous situations. High electrical and mechanical life.


NOTE:
Switch for disconnection without overload and short circuit protection function.

Specifications:

  • Manufacturer: Hyundai Electric
  • Reference: HGM400-NA4PDS400
  • Caliber (In): 400A
  • Number of poles: 4
  • Rated insulation voltage (Ui) : 1.000V
  • Maximum operating voltage (Ue): 690V
  • Nominal impulse voltage (Uimp): 8kV
  • Thermal intensity in the environment at 60ºC: 400A
  • Employ intensity (Ie) 690AC (50/60Hz): 400A
  • Assigned short-circuit closing power (Icm): 6.8kA (peak)
  • Permissible short-duration allocated current (Icw): 4kA rms
  • Mechanical durability: 4,000 cycles
  • Use category: AC 22A/ AC 23A - DC 22A/DC 23A
  • Front connection: Screw terminal
  • Rear connection: Horizontal/Vertical
  • Dimensions: 184x257x110 mm
  • Weight: 5,4 Kg
  • Degree of protection: IP20
  • Standard: IEC60947-3




To expand the information, you can download the data sheet by clicking on the "Attachments" tab.

Material for professional use, must be installed by qualified personnel respecting the regulations in force at the site of installation.
