Tetrapolar load cutting disconnector switch 4x630A - Hyundai Electric

€654.78 Tax included

€541.14 tax excl.

Load cut disconnector switch in molded box format 4 poles of 630A of nominal current. Switch for disconnection without protection function with high operating capacity under load and with a high level of insulation in sectioning, high reliability and safety in anomalous situations. High electrical and mechanical life.

Reference: HGM630-NA4PDS630




Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!


Switch-disconnector of cut in load in molded box format 4 poles of 630A of nominal current. It is a switch for disconnection under load without protection function, with high operating capacity under load and with a high level of insulation in sectioning, high reliability and safety in anomalous situations. High electrical and mechanical life.


NOTE:
Switch for disconnection without overload and short circuit protection function.

Specifications:

  • Manufacturer: Hyundai Electric
  • Reference: HGM630-NA4PDS630
  • Caliber (In): 630A
  • Number of poles: 4
  • Rated insulation voltage (Ui) : 1.000V
  • Maximum operating voltage (Ue): 690V
  • Nominal impulse voltage (Uimp): 8kV
  • Thermal intensity in the environment at 60ºC: 630A
  • Employ intensity (Ie) 690AC (50/60Hz): 630A
  • Assigned short-circuit closing power (Icm): 10.7kA (peak)
  • Permissible short-duration allocated current (Icw): 6.3kA rms
  • Mechanical durability: 2,500 cycles
  • Use category: AC 22A/ AC 23A - DC 22A/DC 23A
  • Front connection: Screw terminal
  • Rear connection: Horizontal/Vertical
  • Dimensions: 280x280x110 mm
  • Weight: 12,5 Kg
  • Degree of protection: IP20
  • Standard: IEC60947-3




To expand the information, you can download the data sheet by clicking on the "Attachments" tab.

Material for professional use, must be installed by qualified personnel respecting the regulations in force at the site of installation.
