MCB circuit breaker 3 poles 63A 10kA (3x63A) - LS
MCB circuit breaker 3 poles 63A 10kA (3x63A) - LS

Circuit breaker 3 poles 63A 10kA (3x63A) - LS

€87.18 Tax included

€72.65 tax excl.

97BKH3PC63A

Circuit breaker 3 poles 63A curve C, for protection against short circuits and overloads in single-phase or two-phase installations, of the LS brand. With a rated breaking capacity capacity of 10000A (10kA) and active pole protection with individual status indication for each pole.

Reference: BKH 3P C63A

2-pole circuit breaker electrical diagram

LS logo

Representative image for illustrative purposes, the supplied article will correspond to the indicated specifications.

Out of stock

No queries yet, leave the first!
Privacy
Shipments
Returns


Circuit breaker 3 poles 63A 10kA curve C, for protection against short circuits and overloads in single-phase or two-phase installations. With a rated breaking capacity capacity of 10000A (10kA) and active pole protection with individual status indication for each pole.

Width per module of 27mm, with a connection section of up to 50mm².



Main characteristics of the magnetothermic :

  • Manufacturer/Supplier: LS (LG)
  • Manufacturer reference: BKH 3P C63A
  • Nominal intensity of the magnetothermic (In): 63A
  • Number of poles: 3 (3x63A)
  • Pitch: 3 modules (81mm)
  • Breaking capacity (Icn): 10000A (10kA)
  • Operating voltage: 400Vac, 50/60Hz
  • Characteristic curve: C
  • Endurance: ≥4000
  • Regulations: CE; IEC60947-2
  • Terminal Type: Screw Clamp
  • Capacity for 50mm² cable

OB8-100 circuit breaker dimensions

Material for professional use, install in compliance with the regulations in force at the place of installation.
