Digital multimeter HK36A CAT III 500V
Digital multimeter HK36A CAT III 500V
Digital multimeter HK36A CAT III 500V
Digital multimeter HK36A CAT III 500V
Digital multimeter HK36A CAT III 500V
Digital multimeter HK36A CAT III 500V

Digital multimeter HK36A CAT III 500V

€17.64 Tax included

€14.58 tax excl.

Digital multimeter CAT III 500V, with backlit display. Measurement of DC and AC voltage, DC current, resistance, diode and continuity test, non-contact voltage detection (NVC) and pulse generator. Ideal for use in laboratories, home and other basic applications.

Part No.: HK36A


Representative image for illustrative purposes, the item supplied will correspond to the specifications shown .

No queries yet, leave the first!


Digital multimeter CAT III 500V, with backlit display. Measurement of DC and AC voltage, DC current, resistance, diode and continuity test, non-contact voltage detection (NVC) and pulse generator.

Manufacturer/Supplier: Tracon
Part number: HK36A


Technical specifications:

  • DC voltage: 200mV, 2V, 20V, 200V, 500V
  • AC voltage: 200V, 500V
  • DC Current: 200µA, 2mA, 20mA, 200mA, 10A
  • Resistance: 200Ω, 2kΩ, 20kΩ, 200kΩ, 20MΩ
  • Diodes: 2.5V / 1mA
  • Pulse generation: 5V / 50HZ / 560kΩ
  • Continuity
  • Non-contact voltage detection (NVC)


Other functions and features:

  • 3.5 digit LCD display
  • Backlit display
  • Measurement range selection: Manual
  • HOLD function (data hold)
  • Low battery indicator
  • Auto power off
  • Operating temperature: 0 ~ 40°C
  • Battery: 9V, 6F22 (included)
  • Degree of protection: IP00
  • Dimensions: 150 × 75 × 50 mm
  • Weight: 270gr (including battery)
  • Accessories: Test leads, 9V battery
  • Standards: EN 61010
