Block 4 front NC contacts for TR1K Series mini contactors

Block 4 front NC contacts for TR1K Series mini contactors

€5.70 Tax included

€4.71 tax excl.

Block of 4 closed auxiliary contacts (4NC) for front mounting on TR1K series mini contactors.


Reference: TR5KN04

4block scheme

Representative image for illustrative purposes, the item supplied will correspond to the indicated specifications.

Out of stock

No queries yet, leave the first!
Privacy
Shipments
Returns


Block of 4 auxiliary contacts for front mounting on mini contactor, the camera has 4 closed contacts (4 NC).

This contact block is valid for TR1K series mini contactors.



Characteristics:

  • Manufacturer/Supplier: Tracon
  • Reference: TR5KN04
  • Contacts : 4 closed contacts (4NC)
  • Mounting mode: Front
  • Rated operating voltage (Ue): 660V
  • Rated insulation voltage (Ui): 690V
  • Thermal current rating (Ith): 10A
  • Nominal operating current (Ie): 2A
  • Working temperature: -25ºC to +50ºC
  • Protection grade: IP20



Dimensions:

TR5DIMENSIONS




Material for professional use, it must be installed by qualified personnel, respecting the regulations in force at the installation site.
