Limit switch 1/8 3/2 NC strut pneumatic - monostable with spring return Aignep

Name: Limit switch 1/8 3/2 NC strut pneumatic - monostable with spring return Aignep
Brand: Aignep
SKU: 03VG03NC02
Price: 23.208 EUR
Availability: PreOrder

€23.21 Tax included

€19.34 tax excl.

Limit switch pneumatic 1/8 3 way and 2 positions, for mounting with emergency push button or similar. Actuated by spring return mechanical strut.

Series: 03V
Reference: 03VG03NC02

Logotipo Aignep

Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!

Privacy

Shipments

Returns

Limit switch pneumatic 1/8 3 way and 2 positions, normally closed (NC), monostable, actuated by spring return mechanical strut. Limit switch connections are by 1/8" thread (fittings located on the side of the valve).

Manufacturer: Aignep

Part No.: 03VG03NC02
Valve body: anodized aluminum
Spring material: stainless steel
Seals: NBR
Actuating force: 19,6 N
Operating pressure: 2 ÷ 10
Operating temperature °C: -10 ÷ +60
Flow rate at 6 bar ΔP 1 bar Nl/min: 350

03VG03NC02

Material for professional use, install in compliance with the regulations in force at the place of installation.

For further information you can download the technical data sheet by clicking on the "Attachments" tab

AIGNEP 03V series catalog

Download (4.14MB)
