Pneumatic valve 1/4 3 way monostable closed NC - Aignep

Pneumatic valve 1/4 3 way monostable closed NC - Aignep

€31.75 Tax included

€26.24 tax excl.

Valve 1/4 3 way monostable normally open closed (NC), pneumatic pilot and spring return, with G 1/4" threads. Anodized aluminum body, NBR seals.


Part no.: 01V P0 3 NC 03

Simbolo neumatico valvula 3 vias monoestable NC Adajusa
Logotipo Aignep


Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!


Pneumatic valve 1/4 3 way monostable , for general and industrial applications. The valve is normally closed (NC), i.e. no pilot pressure, the inlet is not connected to the outlet, there is no air pressure at the outlet, the outlet is connected to the exhaust. When pressure is received through the pilot inlet, air circulation occurs between inlet and outlet.

Body made of anodized and varnished aluminum, slide in chemically nickel plated aluminum and seals in NBR.


Characteristics:

  • Pneumatic valve 1/4 3 way monostable normally closed (NC)
  • Manufacturer: Aignep
  • Part number: 01VP03NC03
  • Operating pressure: 2 - 10 bar
  • Actuating pressure: 0 - 10 bar
  • Operating temperature: -10ºC to +60ºC
  • Flow rate at 6 bar ΔP 1 bar: 1200Nl/min



Equipment for professional use, install in compliance with the regulations in force at the installation site.

For further information, please download the data sheet by clicking on the "Attachments" tab
