Bearing 7207-2RS 35x72x17mm - FAG

€159.42 Tax included

€131.75 tax excl.

7207 single row angular contact ball bearing , dimensions 35x72x17mm, sealed with two lip caps for closure (2RS) on both sides. Made of steel with polyamide cage.

Reference: 7207 B-XL-2RS-TVP

FAG brand

Representative image for illustrative purposes, the item supplied will correspond to the indicated specifications.

No queries yet, leave the first!


Angular contact ball bearing, single row, series 7207 according to DIN 628-1, or sealed with metal protective caps for closure on both sides. They are supplied already lubricated and with a polyamide cage.

This series of bearings with suffix 2RS (2RSR) are provided with protective caps on both sides of the bearings, this type of contact seals are ideal for protection against dust, dirt and humid environments.

Single row angular contact ball bearings support high radial loads and axial forces in only one direction, the contact angle of this series is 40º. The usual assembly of this type of bearings is in combination with another bearing .

This type of bearings are suitable for operating temperatures from -30ºC to +110ºC.

Dimensions: Ø35xØ72x17

For other references or measurements, consult.

DrawingBearingAngularFAG

Characteristics:

  • Manufacturer FAG
  • Reference: 7207 B-XL-2RS-TVP
  • Material: Tempered steel
  • Cage: Polyamide
  • Dimension d: 35mm
  • Dimension D: 72mm
  • Dimension B: 17mm
  • Seal: Type 2RS elastic (NBR) on both sides.
  • Dynamic load capacity Cᵣ (N): 28000
  • Static load capacity C₀ᵣ (N): 19000
  • Contact angle: ἀ=40º
  • Limit speed ng (min⁻¹): 5600
  • Weight: 0.282Kg

Material for professional use, install in compliance with the regulations in force at the installation site.
