MCB circuit breaker Differential 25A 300mA Class A Narrow Profile - Hyundai Electric
MCB circuit breaker Differential 25A 300mA Class A Narrow Profile - Hyundai Electric

Circuit breaker Differential 25A 300mA Class A Narrow Profile - Hyundai Electric

€38.80 Tax included

€32.07 tax excl.

Differential MCB circuit breaker 25A 300mA (0.3A) Class A, Pole + Neutral, Class C Trigger Curve, 6kA Cutting Power. This device combines differential and MCB circuit breaker functions in a single element for the protection of people and lines. Using these elements simplifies connection and saves space in the distribution box.

Ref: HRO-MN1025C300

hyundai electric logotipo A

No queries yet, leave the first!


MCB circuit breaker and differential integrated into the same element, Pole + Neutral. This modular device with a narrow profile, perfectly integrates a differential and a MCB circuit breaker, allowing a space saving and in connection time.

The differential is high sensitivity 300mA (0.3A) non-adjustable. The protection of the MCB circuit breaker is on a phase by cutting the phase and neutral in case of action (Polo+Neutro). The MCB circuit breaker trigger curve is "C", cutting power of 6kA.

Compact manufacture in box of molded thermoplastic material, has status indication in the font (Red-ON, Green-OFF)

Technical details:

  • Manufacturer: Hyundai Electric
  • Reference: HRO40-MN1025C300
  • Component type: differential MCB circuit breaker
  • Number of poles: Polo + Neutral
  • Class: A
  • Employment voltage: 250Vac
  • Nominal Intensity (In): 25A
  • Sensitivity (I'n): 300mA (0.0A)
  • Cutting power (Icn): 6kA
  • Curve: C
  • Visual contact position indicator: Red-ON, Green-OFF
  • Degree of protection IP20
  • Maximum terminal size: 25mm2
  • Installation position: Vertical/Horizontal
  • Dimensions (Height x Depth x Width): 83 x 71.8 x 17.8mm
  • Housing and cover: Molded thermoplastic material, fireproof
  • Auxiliary contacts: NO.
